DATALOGIC

Datalogic - Quick Link 100

Quick Link is a complete series for fast, easy cabling of an ID-NET™ network by means of standard cables. QL100/150/200 are slave modules designed for use with the master modules QL300/500 or CBX100/500. Quick Link 100 is a T-connector used in ID-NET™ networks for distributing signals and supply voltage to the reader.

Pokaż więcej
  • Fast, easy connection for ID-NET™ networks
  • Compact dimensions
  • Time-saving solution

Wybrany wariant produktu


QL100 ID-NET T-CONNECTION

Nr produktu:

Wybrany wariant produktu

Specyfikacja techniczna

Masa 115 g
Max. temperatura pracy 50 °C
Max. temperatura składowania 70 °C
Min. temperatura pracy 0 °C
Min. temperatura składowania -20 °C
Napięcie zasilania DC max. 30 V DC
Napięcie zasilania DC min. 10 V DC
Pobór mocy (max) 4 A
Stopień ochrony IP IP65

Opis produktu

Quick Link is a complete series for fast, easy cabling of an ID-NET™ network by means of standard cables. QL100/150/200 are slave modules designed for use with the master modules QL300/500 or CBX100/500. Quick Link 100 is a T-connector used in ID-NET™ networks for distributing signals and supply voltage to the reader.
