Datalogic - Quick Link 300

Quick Link is a complete series for fast, easy cabling of an ID-NET™ network by means of standard cables. QL300 is a passive master module designed for use with the slave modules QL100/150/200, but it can also be used as an independent unit. QL300 has separate ports for supply voltage, external trigger signal, Digital I/O and communication.

Pokaż więcej
  • Fast, easy connection for ID-NET™ networks
  • Compact dimensions
  • Passive master module

Wybrany wariant produktu


QL300 STANDARD CONNECTION MODULE

Nr produktu:

Wybrany wariant produktu

Specyfikacja techniczna

Masa 312 g
Max. temperatura pracy 50 °C
Max. temperatura składowania 70 °C
Min. temperatura pracy 0 °C
Min. temperatura składowania -20 °C
Napięcie zasilania DC max. 30 V DC
Napięcie zasilania DC min. 10 V DC
Pobór mocy (max) 4 A
Stopień ochrony IP IP65

Opis produktu

Quick Link is a complete series for fast, easy cabling of an ID-NET™ network by means of standard cables. QL300 is a passive master module designed for use with the slave modules QL100/150/200, but it can also be used as an independent unit. QL300 has separate ports for supply voltage, external trigger signal, Digital I/O and communication.
